Compact Devices Regula 10XX
Handheld Device for Quick On-Site Document Checks
Highlighted Features
White lights
Incident, oblique (8 light sources), for OVD visualization (8 light sources), coaxial.
UV lights
254, 313, 365, 400 nm.
IR lights
Incident 850 nm, high-intensity 980 nm.
Front torch
White, ultraviolet 365 nm.
RFID check
Models 1029, 1030 and 1031 have a built-in module for scanning RFID that instantly detects, identifies, and displays the type of RFID tag embedded in passports and other documents.
OLED display
The top-of-the-line Regula 1031 now has an OLED display that indicates the battery charge level and operating mode, as well as, RFID chip type.
Up to 24x magnification
Depending on the modification, Regula 10XX offers 10x, 15x, 20x, or even 24x magnification that enables examination of microprinting and even nano printing, as well as, detection of printing methods, and different security features.
Measuring scale
Linear, angular, radial measuring scale which helps to estimate and compare sizes of document security features and to estimate the width of typographical lines.
New built-in battery
The updated models has a built-in Li-Pol battery with charging through a USB type C port, so now you can charge the device like an ordinary smartphone. The device's body is made of shockproof plastic. Optionally, the device comes with a special case for convenient fastening on a belt, and a wrist strap.
Intended Objects for Examination
Examples of Examination
Document examination in different light sources
Efficient Solution for a Variety of Sectors
Specifications
Does not constitute а public offer
Light sources
White
incident, oblique (8 light sources), for OVD visualization (8 light sources), coaxial
Ultraviolet
254, 313, 365, 400 nm
Infrared
incident 850 nm, high-intensity 980 nm
Torch
white, ultraviolet 365 nm
Interchangeable white/ultraviolet
in model 1025 only
Optical parameters
Magnification
Field of view, mm
10x
20±2
15x
12±2
20x
8±1
24x
6,5±1
Additional features
Detector of radio frequency identification devices
detecting and identifying (type A and B)
OLED display
indication of operation mode, charge level, and RFID tag type
Measuring scale
linear, angular, radial
General parameters
Dimensions
102×60×45 mm
Weight
0.2 kg
Models
| 1019 | 1025 | 1029 | 1030 | 1031 | |
|---|---|---|---|---|---|
| LIGHT SOURCES | |||||
| Incident white | |||||
| Oblique white | |||||
| White for OVD visualization | |||||
| Coaxial white | |||||
| Interchangeable white/ultraviolet | |||||
| Ultraviolet 254 nm | |||||
| Ultraviolet 313 nm | |||||
| Ultraviolet 365 nm | |||||
| Ultraviolet 400 nm | |||||
| Infrared incident 850 nm | |||||
| High-intensity IR 980 nm | 2 modes | ||||
| Torch white | |||||
| Torch ultraviolet 365 nm | |||||
| Detector of radio frequency identification devices (RFID) | |||||
| Magnification, times | 10/15 | 10/15 | 15 | 15/20/24 | 15/20/24 |
| Diopter adjustment, dptr | ±2 | ±2 | ±2 | ±2 | ±2 |
| Measuring scale (optionally) |
